Outage Scheduler Viewer
The web based Transmission Outage Viewer (TOV) was originally developed by eMIT LLC for an EPRI R&D project. It is a patented product, US patent No. 20090287739, and has the following main features:
Provide Gantt chart type outage display to enter and review update outage requests on monthly, weekly and hourly basis
Show a scrollable Gantt chart of all schedules for the specified time interval.
Display outage schedules on company basis, control area basis, zone basis or on system basis
Display outage schedules on facility type (generators, lines, transformers) basis or on voltage level basis
Display certain outaged transmission lines (tie-lines or flowgate elements) with special indications.
Allow user to add new outage schedules into the chart or update the existing outage schedules
Allow administrator to specify roles and authority for each user
Allow user to move outages, increase or shorten outage duration on the Gantt chart display.
Show outages in different colors based on voltage levels
Show outages in different height of Gantt chart bar according to the maximum capacity of the outage element (generator or transmission line / transformer).
Allow the administrator to configure the voltage level color scheme
Right click on an outage bar and add additional textual attributes to the schedule.
Implement a pre-defined outage schedule workflow process, such as approval and denial.
Show the processing status of each outage
Display load forecast curve for control area or RTO/ISO
Calculate and display generation / transmission reliability indices
Store outage schedule information in a relational database
Automates Utility Company's outage schedule interface with RTO/ISO
Import / export outages in SDX format
Import transmission / generation reliability indices
